PAC Racing - PAC-1231X - 1.083 Valve Springs - Ovate Beehive (16)

Product Images may differ from the actual product. Image may be a representation of this item.

The price includes any freight from the supplier to the Store

Produktbeskrivelse

Valve Spring - RPM Series - Ovate Beehive Spring - 291 lb/in Spring Rate - 0.952 in Coil Bind - 0.999 in / 1.083 in OD - Set of 16

Additional information
Outer Diameter (Bottom): 1.083 in
Inner Diameter (Bottom): 0.999 in
Outer Diameter (Top): 0.720 in
Inner Diameter (Top): 0.636 in
Installed Height (Valve Closed): 1.575 in
Seat Pressure @ 1.575 in: 120 lbs
Open Pressure @ 1.025 in: 280 lbs
Spring Rate: 291 lb/in
Coil Bind Height: 0.952 in
Max Valve Lift: 0.550 in

Recommended components:
Retainers: N/A

Application notes:
Ford 5.4L GT500 and Cobra Jet high-lift exhaust spring. Fits stock retainers and seats.

racingsprings.com

Vendor Part Number: PAC-1231X

Pac Racing Catalog -24
Pac Racing Catalog -15

Always verify specifications with the manufacturer and engine builder before final assembly.

Den omtrentlige pakkestørrelse eller størrelsen på produktets pakke er 103 x 92 x 388 mm.

Spring Type
Beehive

Vægt
1 kg(Produktet kan have let salgspakning.)
