PAC Racing - PAC-1219 - 1.307 Valve Spring - Ovate Beehive (1)

Valve Spring - 1200 Series - Ovate Beehive Spring - 340 lb/in Spring Rate - 1.100 in Coil Bind - 1.072 in / 1.307 in OD - GM LS-Series - Each

Lisätiedot
Outer Diameter (Bottom): 1.307 in
Inner Diameter (Bottom): 1.072 in
Outer Diameter (Top): 0.885 in
Inner Diameter (Top): 0.650 in
Installed Height (Valve Closed): 1.800 in
Seat Pressure @ 1.800 in: 135 lbs
Open Pressure @ 1.175 in: 348 lbs
Spring Rate: 340 lb/in
Coil Bind Height: 1.115 in
Max Valve Lift: 0.625 in

Recommended components:
Retainers (PAC 300 Series): R310, R311, R362, R363
Retainers (PAC 500 Series): R510, R511
Spring Seats: S111

Käyttöhuomiot:
Higher rate and frequency for aggressive LS camshafts. Drop-in design.


racingsprings.com

Valmistajan osanumero: PAC-1219

Pac Racing Catalog -24
Pac Racing Catalog -15

Tekniset tiedot tulee aina varmistaa valmistajalta ja moottorinrakentajalta ennen lopullista kokoonpanoa.
